Mercury, Mariner Application Charts
HP Model Cyl. Year Serial Number Switch Box Stator Trigger Rec./Reg. Harness
20 - 2 97-98 0G438000-0G760299 114-4952A30 174-6617A17 R98450A10* 154-6770 R84-92436A5*
20 Comm 2 98-06 0G760300-0T979999 114-5713 174-5721(b) R98450A10* 154-6770 R84-92436A 9*
20 - 2 98-06 0G760300-0T979999 114-5713 174-5721(b) R98450A10* 154-6770 R84-92436A 9*
25 XD 2 79-87 5837437-B114230 114-7452A3 174-6617K 1 R98450A10* - R84-88891A1*
25 - 2 79-87 5705532-0B238463 114-7452A3 174-6617K 1 R98450A10* - -
25 - 2 79-87 5705532-0B238463 114-7452K1 174-6617K 1 R98450A10* - -
25 - 2 88-93 0B238464-0G044365 114-7452K1 174-6617K 1 R98450A10* - -
25 Sea Pro 2 96-97 0G438000-0G760299 114-7452K1 174-6617K 1 R98450A10* 154-6770 -
25 XD 2 98-06 0G760300-0T979999 114-5713 174-5721(b) R98450A10* 154-6770 R84-92436A 9*
25 Jet 20 2 94-97 0G044027-0G437999 114-4952A30 174-6617A17 R98450A10* 154-6770 -
25 Elec Str 4 Stk 2 98 0G590000-0G760299 **856482 2 174-2387 - 194-5279 R84-830279A 4*
25 Man. Str. 4 Stk 2 98 0G590000-0G760299 **856482 2 174-2386 - - R84-850162A 2*
25 Elec Str 4 Stk 2 99-01 0G760300-0T178499 **8478433A 3 174-2387 - 194-2115K 1 R84-859202T 1*
25 Elec Str 4 Stk 2 2001 0T178500-0T408999 **8478433A 3 174-2387 - 194-2115K 1 R84-859202T 2*
25 Man. Str. 4 Stk 2 2001 0G760300-0G960499 **8478433A 3 174-2386 - - R84-850167A 7*
25 Man. Str. 4 Stk 2 2001 0G960500-0T408999 **8478433A 3 174-2386 - - R84-850167A 7*
25 Elec Str 4 Stk 2 02-05 0T409000-1B344298 **87843301S 174-2387 - 194-2115K 1 R84-859202T 2*
25 Man. Str. 4 Stk 2 02-05 0T409000-1B344298 **87843301S 174-2386 - - R84-859201T 1*
30 Elec Str 2 95-96 0G055314-0G380074 114-7509K1
144-3251A 5
174-2075K 1 134-9021-2 194-5279 R84-824477A 4*
30 Man. Str. 2 95-96 0G055314-0G380074 114-7509K1
144-3251A 5
R398-832074A 5* 134-9021-2 194-5279 R84-824456A 2*
30 Elec Str. 2 96-99 0G380075-0G589999 114-7509K1
144-3251A 6
174-2075K 2 134-9021-2 194-5279 R84-830574A2*
30 Man. Str 2 96-99 0G380075-0G589999 114-7509K1
144-3251A 6
174-2075K 1 134-9021-2 - R84-854323A 2*
30 Man. Str. 2 98-99 0G590000-0G760299 114-7509 174-2075K 1 134-3960-2 - R84-824456A 2*
30 Elec Str. 2 98-99 0G590000-0G760299 114-7509 174-2075K 2 134-3960-2 194-5279 R84-824477A 4*
30 Man. Str. 2 99-06 0G760300-0T979999 114-7509 174-2075K 1 134-3960-2 - R84-854323A 2*
30 Elec Str. 2 99-06 0G760300-0T979999 114-7509 174-2075K 2 134-3960-2 194-5279 R84-854322A 2*
30 Jet 4 89-97 C159200-0G589999 114-5772 174-9710K 1 134-6452(c) 194-5279 414-8672
30 Jet 3 98-01 0G590000-0T408999 114-7509 174-2075K 2 134-4512-3 194-5279 414-0220
30 Elec Str 4 Stk 3 02-05 0T178500-0T178499 **87843302S 174-2387 - 194-2115K 1 R84-859197T 3*
30 Man. Str. 4 Stk 3 02-05 0T178500-0T178499 **87843302S 174-2386 - - R84-859196T 1*
30 4 Stroke EFI 3 02-05 0T409000-0T800999 - R398-878143T 3* - 194-2115K 1 R84-878132T 3*
30 4 Stroke EFI 3 02-05 0T801000-1B344298 - R398-878143T05* - 194-2115K 1 R84-878132T04*
35 350 2 68 1960827-2874703 - **398-2568A 1
Magneto
- - R84-34229*
35 - 2 84-86 6445653-0B110788 114-7452A3 174-6617K 1 R92431A 1 154-6770 414-6219A 2
35 - 2 84-86 6445653-0B110788 114-7452K1 174-6617K 1 R92431A 6 - 414-6219A 5
35 - 2 87-89 0B110789-0B393190 114-7452K1 174-6617K 1 R92431A 6 154-6770 414-6219A 5
40 400 Elec Str. 2 70-71 2874704-3336237 R332-4172 174-4424 - 154-6770 414-2770
40 400 Man. Str. 2 70-71 2874704-3336237 R332-4172 174-4424 - - -
40 402 Elec Str. 2 72-74 3336258-3859434
114-4911 174-5255 R338-4731A6* 154-6770 414-2770
40 402 Man. Str. 2 72-74 3336258-4117709 114-4911 174-5255 R338-4731A6* - -
40 402 Elec Str. 2 75-77 4117710-4860102 114-4911 174-5255 R338-4731A6* 154-6770 414-2770
40 Man. Str. 2 75-81 4117710-5823917 114-4911 174-5255 R338-4731A6* - -
40 Elec Str. 2 78-81 4860103-5823917 114-4911 174-5255 R338-4731A6* 154-6770 414-2770
*Premier Services Availability Only **Part Currently Unavailable by CDI Electronics at this time (a) Use 994-4463 (b) Auxillary Charging Stator is Premier Services Only (c) If Linkage 90 Deg., Order 134-6454
(d) If Linkage Straight, Order 134-6452 (e) Order 114-2986K 1 if original had 337-4406 (f) Order 194-1873 if Stator has 2 Yellow Wires (g) Replaces both Rectifier & Regulator
