Mercury/Mariner Outboard (Cont.)

CSS Drop Down Menu by PureCSSMenu.com < Previous Page|Next Page >
6‑15 Horsepower ‑ Mercury/Mariner
6, 8, 9.9 and 15 HP 2‑Strokes 1986 & Newer
10, 15 HP Seapro/Marathon 1995 & Newer
8/9.9 HP (Not Bigfoot) 4‑Strokes 1995‑2004
15 HP 4 Stroke 1989‑2006
8 Tooth Spline
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
Work/Sail 6-13 / 10-21 9 3/4 X 5 1/2 RH AL 3 Black Diamond QA2120R 48-828150A12 Rubber Bushing
Work/Sail 10-15 / 16-24 9 3/4 X 6 1/2 RH AL 3 Black Diamond QA2122R 48-828150A12 Rubber Bushing
Kicker 9 3/4 X 6 AL 4 Black Diamond 48-850204A12 48-850204A12 Rubber Bushing
15-20 / 4.5-6.1 12-17 / 19-27 9 1/4 X 7 RH AL 3 Black Diamond QA2124R 48-828152A12 Rubber Bushing
14-20 / 4.2-6.1 16-19 / 26-31 9 X 8 RH AL 3 Black Diamond QA2126R 48-828154A12 Rubber Bushing
14-19 / 4.2-5.8 19-24 / 31-39 9 X 9 RH AL 3 Black Diamond QA2128R 48-828156A12(1) Rubber Bushing
14-16 / 4.2-4.8 23-27 / 37-44 9 X 10 1/2 RH AL 3 Black Diamond QA2130R 48-828158A12 Rubber Bushing
(1) Standard with 6-15 Hp 2-Stroke and SeaPro/Marathon 10-15 Hp
15‑25 Horsepower ‑ Mariner
15 HP 1976‑81 Mariner
15A 1979‑82 Mariner
W15 1977‑85 Mariner
20 HP 1976‑79 Mariner
25 HP 1977‑79 Mariner
Pin Drive
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
12-16 / 3.6-4.8 20-28 / 32-45 9 X 10 RH AL 3 Black Diamond QA3150R 96625M Rubber Bushing
12-14 / 3.6-4.2 25-32 / 40-52 9 1/4 X 11 RH AL 3 Black Diamond QA3152R 96623M Rubber Bushing
9.9‑25 Horsepower ‑ Mercury/Mariner
9.9 & 15 HP Bigfoot 4‑Strokes 2005 & Older
9.9 Sail Power 4 Strokes 2005 & Older
18 HP Mercury 1980‑85
20 HP Mariner 1985 & Newer
20 HP Mercury 2 Stroke 1986 & Newer
25 HP Mercury 2 Stroke 1980 & Newer
25 HP Mariner 2 Stroke 1985 & Newer
25 HP SeaPro/Marathon
10 Tooth Spline
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
Work/Sail 10-15/16-24 10.4 X 9.5 RH AL 3 Black Diamond 48-8M0069664 48-19636A10 Rubber Bushing
15-20 / 4.5-6.1 11-24 / 18-34 10 3/8 X 11 RH AL 3 Black Diamond QA2102R 48-19638A40 Rubber Bushing
13-18 / 4.0-5..3 15-27 / 24-42 10.4 X 12 RH AL 3 Black Diamond 48-8M0069665 48-19639A40 Rubber Bushing
12-15 / 3.6-4.5 19-30 / 31-48 10 3/8 X 13 RH AL 3 Black Diamond QA2106R 48-19640A40(1) Rubber Bushing
to 14 / to 4.2 21-36 / 34-58 10 1/4 X 14 1/2 RH AL 3 Black Diamond QA2108R 48-19642A40 Rubber Bushing
12-15 / 3.6-4.5 19-30 / 31-48 10 3/8 X 13 RH SS 3 Silverado QS5180R 48-19644A 5 Rubber Bushing
(1) Standard with 20-25 Hp 2-Stroke
15/20 Hp 4‑Stroke, 9.9 HP Bigfoot 4‑Stroke Mercury/Mariner
9.9 Big Foot Model Year 2005 and Newer
15/20 HP 4‑Stroke 2007 and Newer
14 Tooth Spline
Length
Current MPH/KPH Propeller Size Material Blades Style Quicksilver P/N OEM P/N Hub System
Kicker 10 x 5 AL 4 Black Diamond QA2178R 48-812952A10 Rubber Hub
Kicker 10 x 7 AL 4 Black Diamond QA2180R 48-812950A10(1) Rubber Hub
15-19 / 4.6-5.8 5-12 / 8-19 9.5 X 8 RH AL 3 Black Diamond QA2171R 48-897748A11 Rubber Hub
14-17 / 4.3-5.2 10-16 / 16-26 9.25 X 9 RH AL 3 Black Diamond QA2173R 48-897750A11(2) Rubber Hub
to 16 / to 4.9 13-20 / 21-32 9.25 X 10 RH AL 3 Black Diamond QA2175R 48-897752A11(3) Rubber Hub
MERCURY/MARINER OUTBOARD APPLICATION CHARTS
Quicksilver Propeller Guide
