Suzuki Outboard (Cont.)

CSS Drop Down Menu by PureCSSMenu.com < Previous Page|Next Page >
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N Hub System
14-16 / 4.2-4.8 31-35 / 50-56 10.1 X 14 RH AL 4 Nemesis 48-8M8027513 Flo-Torq Reflex(1)
13-15 / 3.9-4.5 34-39 / 55-63 10.1 X 15 RH AL 4 Nemesis 48-8M8027514 Flo-Torq Reflex(1)
to 15 / to 4.5 35-47 / 56-76 10 X 17 RH AL 3 Black Diamond QA2088X Flo-Torq Reflex(1)
15-18 / 4.5-5.5 23-28 / 37-45 11 X 12 RH SS 3 Silverado QS5164X Flo-Torq Reflex(1)
14-18 / 4.2-5.5 27-32 / 44-52 10 1/2 X 13 RH SS 3 Silverado QS5166X Flo-Torq Reflex(1)
14-16 / 4.2-4.8 31-35 / 50-56 10 3/8 X 14 RH SS 3 Silverado QS5168X Flo-Torq Reflex(1)
to 15 / to 4.5 34-39 / 55-63 10 1/4 X 15 RH SS 3 Silverado QS5170X Flo-Torq Reflex(1)
(1) Replace existing forward and aft washer with Quicksilver kit 8M0088039. Purchase separately.
35‑65 Horsepower ‑ Suzuki ‑ Rubber Hub
DT35C HP 1987‑90
DT40, DF40 HP 1983 & Newer
DF 50 1999 and Newer
DT50,50M HP 1983‑84
DT55 HP 1985‑97
DT60 HP 1983‑84
DT65 HP 1985‑97
13 Tooth Spline
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
16-19 / 4.8-5.8 21-25 / 34-40 11 1/2 X 11 RH AL 3 Black Diamond QA2226R 58100-95222-019 Rubber Bushing
14-18 / 4.3-5.5 27-32 / 44-52 11 1/2 X 13 RH AL 3 Black Diamond QA2078X 58100-94313-019 Rubber Bushing
14-16 / 4.3-4.8 31-35 / 50-56 11 1/2 X 14 RH AL 3 Black Diamond QA2232R 58100-95353-019 Rubber Bushing
13-15 / 3.9-4.5 34-39 / 55-63 11 1/2 X 15 RH AL 3 Black Diamond QA2234R 58100-95363-019 Rubber Bushing
to 15 / to 4.5 35-47 / 56-76 11 1/2 X 17 RH AL 3 Black Diamond QA2238R 58100-95382-019 Rubber Bushing
60‑70 Hp (4‑Stroke), 75‑140 Hp (2‑Stroke) ‑ Suzuki
DF60 HP 1998 & Newer
DF70 HP 1998‑2008
DT75 HP 1992‑97
DT75 HP 1983‑91
DT85 HP 1992‑2000
DT85 HP 1979‑91
DT90 HP 1989‑97
DT100 HP 1989 and Newer
DT115, 140 HP 1992 & Newer
DT115, 140 HP 1981‑91
13 Tooth Spline
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
Pontoon - 14 X 10 RH extra cup AL 3 Black Diamond QA3828X (1)
Pontoon - 14 X 11 RH extra cup AL 3 Black Diamond QA3830X (1)
Pontoon - 14 X 13 RH extra cup AL 3 Black Diamond QA3832X (1)
18-20 / 5.5-6.1 25-32 / 40-52 13 3/4 X 15 RH AL 3 Black Diamond QA2208X 58100-95500-019 (1)
17-19 / 5.2-5.8 30-38 / 48-61 13 1/4 X 17 RH AL 3 Black Diamond QA2206X 58100-95511-019 (1)
15-18 / 4.5-5.5 35-41 / 56-66 13 X 19 RH AL 3 Black Diamond QA2204X 58100-95521-019 (1)
14-17 / 4.2-5.2 39-46 / 63-74 12 3/4 X 21 RH AL 3 Black Diamond QA2202X 58100-95530-019 (1)
17-19 / 5.2-5.8 30-38 / 48-61 13 1/8 X 16 RH SS 3 Silverado QS5136X 99105-00100-16P (1)
15-18 / 4.5-5.5 35-41 / 56-66 13 X 18 RH SS 3 Silverado QS5138X 99105-00100-18P (1)
14-17 / 4.2-5.2 39-46 / 63-74 13 1/4 X 20 RH SS 3 Lightspeed QS5140X 99105-00101-20P (1)
to 16 / to 4.8 44-50 / 71-81 13 1/2 X 22 RH SS 3 Lightspeed QS5142X 99105-00100-22P (1)
High Perf. 50-53 / 81-85 13 1/2 X 24 RH SS 3 Lightspeed N.L.A. 99105-00101-24P (1)
(1) Use Flo-Torq II attaching hardware kit 835282Q 1. Purchase separately.
SUZUKI OUTBOARD APPLICATION CHARTS
Quicksilver Propeller Guide
21
