Mercruiser Sterndrive (Cont.)

CSS Drop Down Menu by PureCSSMenu.com < Previous Page|Next Page >
Length (ft/m) Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
to 19 / to 5.8 55-60 / 89-97 13 3/4 X 25 RH SS 3 Lightspeed QS5076X 48-16550A46 (2)
22-26 / 6.7-7.9 36-41 / 58-66 14 X 17 RH SS 4 Typhoon QS6002X 48-825898A48 (2)
21-25 / 6.4-7.6 41-46 / 66-74 14 X 19 RH SS 4 Typhoon QS6004X 48-825900A48 (2)
19-23 / 5.8-7.0 46-51 / 74-82 14 X 21 RH SS 4 Typhoon QS6006X 48-825902A48 (2)
23-27 / 7.0-8.2 26-36 / 42-58 15 3/4 X 15 RH SS 3 Thunderbolt QS5002X 48-19838A46 (2)
22-26 / 6.7-7.9 36-41 / 58-66 15 1/2 X 17 RH SS 3 Thunderbolt QS5004X 48-18278A46 (2)
21-25 / 6.4-7.6 41-46 / 66-74 15 1/4 X 19 RH SS 3 Thunderbolt QS5006X 48-13700A46 (2)
19-23 / 5.8-7.0 46-51 / 74-82 14 3/4 X 21 RH SS 3 Thunderbolt QS5008X 48-13702A46 (2)
to 20 / to 6.1 51-56 / 74-90 14 5/8 X 23 RH SS 3 Thunderbolt QS5010X 48-13704A46 (2)
LH Propellers (1) 15 X 16 LH AL 4 Diamond 4 QA2183X 48-834851A45 (2)
14 1/2 X 18 LH AL 4 Diamond 4 QA2185X 48-834853A45 (2)
14 X 20 LH AL 4 Diamond 4 QA2187X 48-834855A45 (2)
14 1/2 X 17 LH SS 3 Silverado QS5053X 48-16315A46 (2)
14 X 19 LH SS 3 Silverado QS5055X 48-16317A46 (2)
13 3/4 X 21 LH SS 3 Silverado QS5057X 48-16319A46 (2)
13 1/2 X 23 LH SS 3 Silverado QS5059X 48-16321A46 (2)
14 X 19 LH SS 3 Lightspeed QS5071X 48-16543A46 (2)
13 7/8 X 21 LH SS 3 Lightspeed QS5073X 48-16545A46 (2)
13 3/4 X 23 LH SS 3 Lightspeed QS5075X 48-16547A46 (2)
13 3/4 X 25 LH SS 3 Lightspeed N.L.A. 48-16549A46 (2)
14 X 17 LH SS 4 Typhoon QS6001X 48-825899A48 (2)
14 X 19 LH SS 4 Typhoon QS6003X 48-825901A48 (2)
14 X 21 LH SS 4 Typhoon QS6005X 48-825903A48 (2)
15 3/4 X 15 LH SS 3 Thunderbolt QS5003X 48-19841A46 (2)
15 1/2 X 17 LH SS 3 Thunderbolt QS5005X 48-90159A46 (2)
15 1/4 X 19 LH SS 3 Thunderbolt QS5007X 48-13701A46 (2)
14 3/4 X 21 LH SS 3 Thunderbolt QS5009X 48-13703A46 (2)
14 5/8 X 23 LH SS 3 Thunderbolt QS5011X 48-13705A46 (2)
(2) Use Flo-Torq II attaching hardware kit 835257Q 1. Order separate.
ALPHA ONE/BRAVO ONE
Model 330TRS
5.7 Liter 210‑320 HP 1986 & Newer
6.2 Liter 320 HP 2001 & newer
7.4 Liter 300‑385 HP 1988 & Newer
8.1 Liter 375‑425 HP 2001 & Newer
8.2 Liter 390‑415 HP 1990 & Newer
Including 350, 454, 496 & 502 Mag. & 320 EFI
Add 2'' of pitch to suggested size for singe engine applications 385 HP and above.
Caution! Check for adequate blade tip clearance when installing stainless steel propellers. If necessary, switch to Mercury trim tab 822777Q 1 to ensure adequate blade
clearance.
Length (ft/m)
Current MPH/KPH Propeller Size Matl Blades Style Quicksilver P/N OEM P/N Hub System
22-26 / 6.7-7.9 36-41 / 58-66 14 X 17 RH AL 4 Nemesis 48-8M0055534 48-8M0084494 (2)
21-25 / 6.4-7.6 41-46 / 66-74 14 X 19 RH AL 4 Nemesis 48-8M0055535 48-8M0084495 (2)
19-23 / 5.8-7.0 46-51 / 74-82 14 X 21 RH AL 4 Nemesis 48-8M0055536 48-8M0084496 (2)
to 20 / to 6.1 51-56 / 74-90 14 X 23 RH AL 4 Nemesis 48-8M0055537 48-8M0084497 (2)
29+ / 8.8+ to18 / to 29 16 X 11 RH AL 3 Black Diamond QA2000X 48-78112A45 (2)
29-34 / 8.8-10.3 18-25 / 29-40 16 X 12 RH AL 3 Black Diamond QA2002X 48-16436A45 (2)
29-34 / 8.8-10.3 18-30 / 29-48 16 X 13 RH AL 3 Black Diamond QA2004X 48-78114A45 (2)
29-32 / 8.8-9.7 24-35 / 39-56 16 X 14 RH AL 3 Black Diamond QA2006X 48-16438A45 (2)
27-30 / 8.2-9.1 29-40 / 47-65 15 1/2 X 15 RH AL 3 Black Diamond QA2008X 48-78116A45 (2)
26-30 / 8.2-9.1 29-40 / 47-65 16 X 16 RH AL 3 Black Diamond QA2010X 48-16440A45 (2)
25-29 / 7.6-8.8 40-46 / 65-74 15 X 17 RH AL 3 Black Diamond QA1912X 48-832828A45 (2)
24-28 / 7.3-8.9 43-49 / 69-79 15 1/2 X 18 RH AL 3 Black Diamond QA2014X 48-11324A45 (2)
23-26 / 7.0-7.9 46-51 / 74-82 14 1/2 X 19 RH AL 3 Black Diamond QA1916X 48-832830A45 (2)
MERCRUISER STERNDRIVE APPLICATION CHARTS
Quicksilver Propeller Guide
33
