PROPELLER HARDWARE AND ACCESSORIES
FLO-TORQ II HUB KIT SUZUKI
FLO-TORQ II HUB KIT
12-835467 7 Forward thrust washer
Fwd thrust washer
835290A1
Plastic drive sleeve
835290A1
Plastic drive sleeve
Aft adaptor
Aft adaptor
Washer
Spacer
Nut
Nut
Cotter Pin
Cotter pin included with Nut
Suzuki 150‑225 HP 2‑Stroke Outboards and 150‑250 HP 4‑Stroke Outboards. Can
OMC Cobra/Volvo SX sterndrives (19 tooth spline, 1996‑present)
be used with Mercury Racing propellers.
Caution! When installing stainless steel propellers, remove the anode to bearing
carrier and check clearance before operation.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
FLO-TORQ II HUB KIT SUZUKI
FLO-TORQ II HUB KIT YAMAHA
12‑8M80042329
Fwd thrust washer
12-853555Q Forward thrust washer
Plastic drive sleeve
835290A1 Plastic drive sleeve
Aft adaptor
826074Q 1 Aft adaptor
Washer
12-850076 Spacer
Nut
859939 Nut
Cotter Pin
Suzuki 70‑90 HP 2009 and Newer
Yamaha outboards (50‑100 HP, splined forward thrust washer)
Quicksilver Branded, Hanging Box Point of Sale Packaged.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
FLO-TORQ II HUB KIT TOHATSU
FLO-TORQ III HUB KIT YAMAHA
12-853555Q Forward thrust washer
835290A1
Plastic drive sleeve
881940A 1 Drive Sleeve Assembly
826074Q1
Aft adaptor
878584 Aft adaptor
Washer
12-850076 Spacer
Nut
859939 Nut
Cotter Pin
Tohatsu/Nissan (70C, 90‑140 HP)
Yamaha outboards (50‑100 HP, splined forward thrust washer)
Quicksilver Branded, Hanging Box Point of Sale Packaged.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
US Quicksilver Product Guide
123
