INSTRUMENTS
PROVIEW INSTRUMENT HARNESSES
ANALOG GAUGE INTERFACE - DIGITAL ENGINES
Harnesses have ring terminal leads bundled for each gauge.
Converts digital signal to analog
INSTRUMENT HARNESS MAIN- PROVIEW
ANALOG GAUGE INTERFACE KIT
Primary Instrument harness used to connect the ProView gauges to the engine
This kit allows the conversion of a digital signal to an analog signal. (Verado
(10 Pin from engine harness)
engines are on digital platform and this kit must use with analog gauge
installations)
Mercury ProView Gauges
2005 and newer 135‑350 Verado
HOSE KIT
Primary Instrument harness used to connect the ProView gauges to the engine
(10 Pin from engine harness) This harness has connections for Tachometere,
Speed, trim,volt and fuel only.
Mercury ProView Gauges
INSTRUMENT ADAPTER HARNESS
Contains the necessary tubing, tee fitting and instruction sheet to allow the use of a
15 PSI Analog Water Pressure Gauge with the otherwise digital 1.5L OptiMax
outboard.
Fits the 75/90/115hp (1.5L) OptiMax Outboard Engine, Model Year 2004 and
newer.
Used to adapt the ProView main harness to add additional connections
CONVERSION KIT - SMARTCRAFT SENSORS
Mercury ProView Gauges
AGI KIT FOR PROVIEW
New kit that allows you to use SmartCraft gauges on these engines
Gen II (2007) 75 HP ‑ 115 HP 4 stroke engines and newer engines
AGI kit that allows the addition of Digital gauges with ProView gauges
Mercury ProView Gauges
184
