INSTRUMENTS
FLAGSHIP WATER TEMPERATURE GAUGE
FLAGSHIP WATER PRESSURE GAUGE
Anti‑fog lens. 100 deg.‑240 deg.F gauge. White face andChrome bezel; black
Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for connection to light.
graduations.
White face and Chrome bezel; black graduations. Complete kit. Includes 25 ft.(7.6
m) of tubing and hardware.
Fits all MCM/MIE gasoline engines and Mercury/Mariner V‑6 outboards. Sender, if
Replacement hose not sold separate, obtain locally.
not already installed on the outboard, must be purchased separately.
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
Mercury Branded, Box Point of Sale Packaged.
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
outboards require a reducer fitting p/n 22-86306.
FLAGSHIP WATER TEMPERATURE GAUGE
Mercury Branded, Box Point of Sale Packaged.
Anti‑fog lens. 2 to 30 psi gauge with quick‑connect terminals for connection to light.
White face and Chrome bezel; black graduations. Replacement Gauge
Fits Mercury/Mariner 25/30/40/45/50/75/90/115/225 (4‑stroke), all V‑6 (except 3.0L
1998 and older) ; and Force 75, 90 and 120. The 75/90/115/225 FourStroke
outboards require a reducer fitting p/n 22-86306.
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER PRESSURE GAUGE
Anti‑fog lens. 60 deg.‑200 deg.F gauge. White face and Chrome bezel; black
225 FourStroke applications. Coastal flush units require the 12415A 2 temperature
sender kit. Order sender seperately
Fits Mercury/Mariner 25 thru 115 FourStroke, 225 FourStroke, 40 (3 & 4 cyl.), 45,
50/60 (3 cyl.), and 70 to 125 hp ; and 1993 and newer Force outboards (Force
models must order sender FA299791)
Mercury Branded, Box Point of Sale Packaged.
FLAGSHIP WATER PRESSURE GAUGE
Anti‑fog lens. 2 to 40 psi gauge with quick‑connect terminals for connection to light.
White face and Chrome bezel; black graduations. Complete kit. Includes 25 ft.(7.6
m) of tubing and hardware.
Replacement hose not sold separate, obtain locally.
Fits 75‑115 hp EFI FourStroke Outboards, serial number 1B366823 & above.
Mercury Branded, Box Point of Sale Packaged.
Anti‑fog lens. 2 to 40 psi gauge with quick‑connect terminals for connection to light.
White face and Chrome bezel; black graduations.. Replacement gauge only.
Fits 75‑115 hp EFI FourStroke Outboards, serial number 1B366823 & above.
Mercury Branded, Box Point of Sale Packaged.
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for connection to light.
White face and Chrome bezel ; black graduations. Complete kit. Includes 25 ft.(7.6
m) of tubing and hardware.
Replacement hose not sold separate, obtain locally.
Fits Mercury/Mariner 25 E and EL (U.S. S/N 0C192155 and above; Belgium S/N
9548742 and above), 30 to 125 (except four stroke models), 1998 and older V‑6
(3.0L), and Force 40/50.
Mercury Branded, Box Point of Sale Packaged.
Anti‑fog lens. 1 to 15 psi gauge with quick‑connect terminals for connection to light.
White face plate with Chrome bezel ; black graduations. Replacement gauge only.
Fits Mercury/Mariner 25 E and EL (U.S. S/N 0C192155 and above; Belgium S/N
9548742 and above), 30 to 125 (except four stroke models), 1998 and older V‑6
(3.0L), and Force 40/50.
Mercury Branded, Box Point of Sale Packaged.
200
