INSTRUMENTS
FACE PLATE
BEZEL 52 MM
879292012
Face Plate ‑Silver 2 inch (52 MM) Bezel is Proview version only. Used on Depth/
Temp gauges only
VDO FAMILY GAUGES
VDO PRIMARY STATION INSTRUMENTATION -
STANDARD
Bezel‑White 2 inch (52 MM) Bezel is a snap fit that has a taper shape.
BEZEL 52 MM
Pre‑wired panel with 21 pin Deutsch connector for 1.7L stern drives/inboards.
Basic Instrument Set. VDO tach, warning lights for low oil pressure, charge
indicator, glow plug activation, coolant temp., water in fuel. Includes key switch,
Bezel‑Black Flat 2 inch (52 MM) Bezel is a snap fit that has a taper shape.
stop button, instrument lights/audio warning test switch.
Fits MCM.MIE ‑ D1.7L DTI diesels.
BEZEL 52 MM
VDO PRIMARY STATION INSTRUMENTATION -
OPTIONAL
Bezel‑Chrome 2 inch (52 MM) Bezel is a snap fit that has a taper shape.
BEZEL 52 MM
Optional pre‑wired panel with 21 pin Deutsch connector for 1.7L stern drives.
Full Instrument Set. VDO tach, oil pressure, water temperature, battery meter &
trim guage. Also warning lights for low oil pressure, charge indicator, glow plug
activation, coolant temp., water in fuel. Includes key switch, stop button,
instrument lights/audio warning test switch.
Fits MCM D1.7L DTI diesels.
879156005
Bezel‑Black Gloss 2 inch (52 MM) Bezel is a snap fit that has a taper shape.
236
