INSTRUMENTS
MECHANICAL TRIM POSITION INDICATORS - 3
MECHANICAL TRIM POSITION INDICATORS - 4
POINTER
POINTER
Cables not included with indicator kits. Order F5H208/_ cables or
Cables not included with indicator kits. Order F5H208/_ cables or
64‑820676A_ cables to proper length. Trim position indicator and bezel
64‑820676A_ cables to proper length. Trim position indicator and bezel
selection chart available within the Instrument section.
selection chart available within the Instrument section.
TRIM POSITION INDICATOR
TRIM POSITION INDICATOR
3 pointer. Top cable entry. Gray faceplate and black bezel.
4 pointer. Bottom cable entry. Gray faceplate and black bezel.
Fits triple MCM sterndrives or single MCM sterndrive and twin trim tabs.
Fits twin MCM sterndrives and twin trim tabs.
TRIM POSITION INDICATOR
TRIM POSITION INDICATOR
3 pointer. Top cable entry. White faceplate and bezel.
4 pointer. Bottom cable entry. White faceplate and bezel.
Fits triple MCM sterndrives or single MCM sterndrive and twin trim tabs.
Fits twin MCM sterndrives and twin trim tabs.
TRIM POSITION INDICATOR
TRIM POSITION INDICATOR
3 pointer. Bottom cable entry. White faceplate and bezel.
4 pointer. Top cable entry. Gray faceplate and black bezel.
Fits triple MCM sterndrives or single MCM sterndrive and twin trim tabs.
Fits twin MCM sterndrives and twin trim tabs
US Quicksilver Product Guide
249
