REMOTE CONTROLS
MPC PANEL-GEN II- FINGER RELEASE-MCM/MIE
(CHROME)
Comes with 4 ft.(1.22 m) trim and trailer switch harness with the 4 pin Molex
connector. All installations require a separate Ignition Switch and Throttle/Shift
Cables to complete the installation. Neutral safety switch leads are 6.5 ft.(1.98 m)
long and have bullet connectors on the ends. Lanyard stop switch leads also have
bullet connectors on ends.
A power trim extension harness also needs to be ordered separately:
(84-881125A 1= 4 pin Molex to traditional Mercury 3 blade P/T
connector).
(84-865772A02 = 4 pin Molex to the Packard 3 pin P/T
connector) Must use Gen II Throttle/Shift Cables design. 897978A__)
Fits all MCM and Mercury/Mariner 3.4L outboards with external trim cylinders. (Ref.
827270A43, A47, A49)
Mercury Branded
CONSOLE CONTROL- SINGLE
Comes with 4 ft.(1.22 m) trim and trailer switch harness with the 4 pin Molex
connector. All installations require a separate Ignition Switch and Throttle/Shift
Cables to complete the installation. Neutral safety switch leads are 6.5 ft.(1.98 m)
Mercury Outboards or Mercruiser
long and have bullet connectors on the ends. Lanyard stop switch leads also have
bullet connectors on ends. Must use Gen II Throttle/Shift Cable design.
(897978A__)
CONSOLE MOUNT REMOTE CONTROL-GEN II- W/O
The power trim extension harness also needs to be ordered separately:
EXT
(84-881125A 1= 4 pin Molex to traditional Mercury 3 blade P/T
connector).
(84-865772A02 = 4 pin Molex to the Packard 3 pin P/T
connector)
Fits all MCM and Mercury/Mariner 3.4L outboards with external trim cylinders. ( Ref
858690A3, A7, A9 and 883709A‑‑ series)
Mercury Branded
PANEL MOUNT REMOTE CONTROL-GEN II- LOCK BAR
New Design. Furnished with single trim switch in handle for trim and trailering. . All
installations require an Ignition/Choke assembly and Throttle/Shift Cables to
complete the installation. Must be used with Gen II Throttle/Shift Cable design.
(897978A__)
A power trim extension harness also needs to be ordered separately:
(84-881125A 1= 4 pin Molex to traditional Mercury 3 blade P/T
connector).
(84-865772A02 = 4 pin Molex to the Packard 3 pin P/T
connector)
Designed for outboards w/o power trim control. All installations require a separate
Fits all MCM applications (ref 883711A13)
Ignition/Choke assembly and Throttle/Shift Cables to complete the installation.
Neutral safety switch and lanyard stop switch leads have bullet connectors on the
CONSOLE REMOTE CONTROL-GEN II-SINGLE
ends. Must use Gen II Throttle/Shift Cables design. 897978A__) 8‑9.9 4 Stroke
engines 2005 and newer will use 896145A series and 8/9.9/generation change
above S/N OR192772 and 15/20 4 Stroke will use Gen II series T/S Cables
Fits Mercury / Mariner outboards (without power trim), and 1993 and newer Force
outboards 40 hp and higher utilizing Mercury style cables (without power trim).
Mercury Branded
Comes with 4 ft.(1.22 m) trim harness with the 3 pin Molex connector. All
installations require a separate Ignition/Choke assembly and Throttle/Shift Cables
to complete the installation. Power trim adapter harness included to convert 3 pin
Molex connector to the traditional 3 blade Mercury connector. Neutral safety switch
leads are 6.5 ft.(1.98 m) long and have bullet connectors on the ends. Lanyard
switch leads also have bullet connectors on ends. Must use Gen II Throttle/Shift
Cables design. 897978A__) 8‑9.9 4 Stroke engines 2005 and newer will use
896145A series and 8/9.9/generation change above S/N OR192772 and 15/20 4
New design. Furnished with single trim switch in handle for trim and trailering.
Stroke will use Gen II series T/S Cable
Comes with 2 ft.(.60 m) trim harness with the traditional 3 blade Mercury connector.
All installations require an Ignition/Choke assembly and Throttle/Shift Cables to
Fits all current Mercury/Mariner outboards (with integral trim) and 1993 and newer
complete the installation. Must use Gen II Throttle/Shift Cables design.
Force outboards 40 hp and higher utilizing Mercury style cables (with power trim).
(897978A__) 8‑9.9 4 Stroke engines 2005 and newer will use Gen II series and
Ref 827270A42, A46, A48
8/9.9/generation change above S/N OR192772 and 15/20 4 Stroke will use Gen II
Mercury Branded
series T/S Cable
Fits all current Mercury/Mariner outboards (with integral trim) and 1993 and newer
Force outboards 40 hp and higher utilizing Mercury style cables (with power trim).
272
