GEAR CASE COMPONENTS
DRAIN SCREW GASKET
There are 4 gaskets included in each clamshell's individual price.
Used with the 3/8‑16 drain/fill screw found on all MerCruiser and most Mercury/
Mariner outboards except Verado and those of Japanese origin.
Priced individually, sold @ multiples of 2
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
DRAIN SCREW GASKET
A rubber coated, stainless steel washer forms a tear resistant gearcase drain
screw seal.
Used with the 3/8‑16 drain/fill screw found on all MerCruiser and most Mercury/
Mariner outboard gearcases except those of Japanese origin..
GEARCASE FILL SCREW
Gearlube fill screw and sealing washer that is located in the bearing carrier.
Fits the standard gearcase on the 135‑300 hp. Verado outboard and the 3.0L
Optimax. Use only if screw location is in the bearing carrier.
US Quicksilver Product Guide
687
