saHara -- With crisp tan dials and fire-orange pointer tip, Sahara gives any dash the elegant OEM look.
Combined red through-dial and white perimeter lighting provide great night readability. These aren't merely
"close enough" -- they're the real thing!
Features:
Tan dial and retainer, black graduations and
numerals, black pointer with fire-orange tip.
Scratch resistant curved glass lenses, with black
matte, near-flush bezels.
White perimeter and red thru-dial lighting.
U.S. and metric scales, with ISO symbols, where
appropriate.
Optional add-on square bezels for modular
appearance (See Gauge Accessories for details).
seLeCtION GuIDe:
GAUGE DESCRIPTION
SIZE
DIAL RANGE
SENDER CODE
PART NUMBER
Fuel Gauge:
2"
E-1/2-F
REQUIRES "F"
Oil Pressure Gauge (Electric):
2"
0-80 PSI
REQUIRES "C"
Speedometer Kits:
35 MPH (Pitot type)
3"
5-35 MPH
INCLUDES "G"
35 MPH (Pitot type) Head Only
3"
5-35 MPH
50 MPH (Pitot type)
3"
10-50 MPH
INCLUDES "G"
65 MPH (Pitot type)
3"
10-65 MPH
INCLUDES "G"
65 MPH (Pitot type) Head Only
3"
10-65 MPH
80 MPH (Pitot type)
3"
20-80 MPH
INCLUDES "G"
80 MPH (Pitot type) Head Only
3"
20-80 MPH
Systems Check � Evinrude/Johnson:
2"
SYSTEM DATA
BY ENG. MFR.
Tachometer (Electric):
O/B & 4-Stroke Gas Engines*
3"
0-7000 RPM
O/B ALT./COIL
Systems Check � Evinrude/Johnson
3"
0-7000 RPM
O/B ALT./COIL
Tach/Hourmeter 0-7000 RPM
3"
0-7000 RPM
O/B ALT./Coil
Trim Gauges (Outboard, I/O):
Evinrude/Johnson Outboard
2"
UP-DOWN
BY ENG. MFR.
Honda Outboards
2"
UP-DOWN
BY ENG. MFR.
Mariner/Merc/Cobra/Volvo DP, SX,
Yamaha 2001 and on
2"
UP-DOWN
BY ENG. MFR.
Suzuki 4-Stroke, 2002 to date
2"
UP-DOWN
BY ENG. MFR.
Voltmeter-12 Volt:
2"
8-18 VDC
NONE REQ'D
Water Pressure Kits (Outboard):**
(Each kit includes fittings
and 20 feet of tubing)
2"
30 PSI
INCLUDES "WP"
Water Temp. Gauge (I/O, I/B):
2"
120-240�F
REQUIRES "D"
Instrument Set "OUTBOARD"
4 Gauge set
Instrument Set "INBOARD/STERNDRIVE"
6 Gauge set
Twin Engine Add On IB/IOGauge Kit
4 Gauge Set
Twin Engine Add On OBGauge Kit
2 Gauge set
Instrument Set OB w/Tach/Hr
4 Gauge Set
Instrument Set IB/IO w/Tach/Hr
6 Gauge set
* Mariner 30 & 40 HP (2-cylinder) engines require a module (Mercury P/N 17461A2) when using any of these tachometers.
Not tested for non-original-equipment (aftermarket) ignition systems. Not for diesels.
** Adapter (P/N 61886P) is required for Yamaha.
11
All gauge products are only available in North America!
