Sierra Marine Parts Catalog
"NAUTALIFTTM STAINLESS STEEL GAS LIFT SUPPORTS"
Marine Grade Gas Filled Supports �
Part No.
OE No.
Extended Compressed Rated
Length
Length
(pounds)
� Designed for demanding
(inches)
(inches)
saltwater applications
GSSX--4900-20
7.5
5.5
20
� 316L Stainless Steel Rod
GSSX--4900-40
7.5
5.5
40
and Cylinder
� Engineered polymer rod ends
GSSX--5000-20
10
7
20
� Bronze bushings
GSSX--5000-40
10
7
40
� Multi-lobe internal seal
GSSX--5100-30
12
8.5
30
GSSX--5150-20
15
9.5
20
GSSX--5150-40
15
9.5
40
GSSX--5150-60
15
9.5
60
GSSX--5200-20
17
11
20
GSSX--5200-40
17
11
40
GSSX--5200-50
17
11
50
GSSX--5200-90
17
11
90
GSSX--5300-20
20
12
20
GSSX--5300-30
20
12
30
GSSX--5300-40
20
12
40
GSSX--5300-60
20
12
60
GSSX--2300-90
20
12
90
GSSX--2300-120
20
12
120
Black zinc plated steel flat
Black zinc plated steel 90�
bracket with 10mm ball stud.
Stainless steel flat bracket with
angle bracket with 10mm ball
2.25" wide.
10mm ball stud. 2.25" wide.
stud. 2" wide, .65" base.
Stainless steel 90� angle
Stainless steel 90� angle
Black zinc plated steel 90�
bracket with 10mm ball
bracket with 10mm ball stud.
angle bracket with 10mm
stud. 2" x 1.2" base.
2" wide, .65" base.
ball stud. 2" x 1.2" base.
Rod end with
internal threads for either end of
Nautalift gas filled lift supports.
Unique construction makes
Zinc plated steel 10mm ball
Stainless steel 10mm ball
24
installation easy and safe.
stud with threaded shaft.
stud with threaded shaft.
