Sierra Marine Parts Catalog
Standard Rocker Switches - with White Actuators
� Non-corrosive plastic construction
� White actuators w/ black face plate
� Silver contacts
� Brass blade terminals
Rated: 20 amps @ 12 VDC
**RK40140W
**RK40150W
**RK40170W
*RK40142W
*RK40152W
*RK40172W
OFF-ON SPST
OFF-MOM ON SPST
ON-OFF-ON SPDT
Illuminated Rocker Switches
� Dependent pilot light - illuminates in "on" position
� Non-corrosive plastic construction
� Silver contacts
� Brass blade terminals
Rated: 20 amps @ 12 VDC
**RK40100
**RK40110
**RK40120
**RK40130
*RK40102
*RK40112
*RK40122
*RK40132
On-Off SPST
On-Off-On SPDT
Mom On - Off SPST
Mom On-Off-Mom On SPDT
Illuminated Rocker Switches - Soft Spot Light
� Independent pilot light - illuminates when panel lights ON
� Illuminates white when panel lights are ON, changes to red when switch is ON
� Soft spotlight helps preserve night vision
� Non-corrosive plastic construction
� Silver contacts
� Brass blade terminals
Rated: 20 amps @ 12 VDC
**RK40370
**RK40380
**RK40390
**RK40400
*RK40372
*RK40382
*RK40392
*RK40402
On-Off SPST
Mom On - Off SPST
On-Off-On SPDT
Mom On-Off-Mom On SPDT
Weather Resistant Illuminated Rocker Switches
� Certified to IP 66 and IP 68 - protected against dust,
prolonged spray and submersion
� Supplied with neoprene mounting gasket
� Removable actuators
� Brass blade terminals, silver contacts
� Snap in lens of choice (Amber, Clear, Green Red)
Rated: 20 amps @12 VDC
**RK19530K
ROCKER SWITCH KIT
**RK19520K
OFF-ON SPST
**RK19510K
**RK19500K
ROCKER SWITCH KIT
ROCKER SWITCH KIT
ROCKER SWITCH KIT
One dependent pilot light -
ON-OFF-ON SPDT
OFF-ON SPST
OFF-ON SPST
illuminates in "on" position. One
Dependent pilot lights - each
Dependent pilot light - illuminates Independent pilot light - illuminates
independent pilot light - illimi-
light illuminates in "on" position
when panel light is turned "on"
in "on" position
nates when panel lights "on"
Includes 2 lenses of each color Includes 2 lenses of each color
Includes 1 lens of each color
Includes 1 lens of each color
39
*BULK - 100 pcs. per carton
**CLAMSHELL
