Sierra Marine Parts Catalog
SHIELDS FLAME RETARDANT
SPLIT WIRE CONDUIT
Flame retardant polypropylene is black with a
blue stripe. It provides chafing protection for
wiring systems and is split longitudinally for easy
access to harness. It has a temperature range
of +275�F.It meets ABYC standard 8.15.19. and
UL 94 V2.
Dist. Pkg.
100' (30.1m)
50' (15.2m)
50' (15.2m)
I.D.
mm
Wt. "C"
Code #
Pack
m
R/O Ctn. Code #
R/O Ctn. Code #
Box Code #
16-128-0140B
16-128-0147B
16-128-0146B
16-128-0146B-1
/4"
6.4
1.26
3200'
975
1
16-128-0380B
16-128-0387B
16-128-0386B
16-128-0386B-1
/8"
9.5
1.58
1800'
549
3
16-128-0120B
16-128-0127B
16-128-0126B
16-128-0126B-1
/2"
12.7
2.31
1100'
335
1
16-128-0580B
16-128-0587B
16-128-0586B
16-128-0586B-1
/8"
15.9
2.94
750'
229
5
16-128-0340B
16-128-0347B
16-128-0346B
16-128-0346B-1
/4"
19.1
3.47
450'
137
3
16-128-1000B
16-128-1007B
16-128-1006B
16-128-1006B-1
1"
25.4
5.78
300'
91
16-128-1140B
16-128-1147B
16-128-1146B
1 1/4"
31.8
9.24
200'
61
--
16-128-1120B
16-128-1126B
1 1/2"
38.1
15.23
100'
31
--
--
16-128-2000B
2"
50.8
21.00
100'
31
--
--
--
SHIELDS STERNFLEX
Shields Sternflex has a polyethylene co-polymer
wall with an integral polyethylene helix. It is resistant
to abrasion, crushing and UV. This hose is primarily
used as a cover for the harness and for the hoses
on the bracket mounted on outboard engines.
Bulk Pack
Dist. Pkg.
Bend
50' (15.2m)
10' (3.1m)
I.D.
mm
Radius
mm
Wt. "C"
Length Code No.
Box Code No.
16-126-2000B
16-126-2003B
2"
50.8
3
76.2
39
RIGGING FLANGE
RIGGING HOSE KIT
18-9761 - Part No.
18-9883 - Part No.
N-189761 - Bulk Part No.
�
Hides all engine cables and hoses
�
U/V stabilized black plastic flange
�
Can be added to any style outboard
�
Use with Shields
�
Contains:
2" Sternflex P/N 16-126-2000B
- (1) U/V stabilized flange
- 5' 2" Black Sternflex
101
