Sierra Marine Parts Catalog: Mercury Mariner
(2 Wire w/ Relays)
TILT/TRIM MOTOR
High Performance Cartridge Pump
TRIM ASSEMBLY
w/Replaceable Motor
TILT/TRIM MOTOR
(REMANUFACTURED)
Replaces: 99186, 99186-1, 99186-T
Fits: Mercury 35-220 HP (1985-92) w/ Design I, 3-Ram
Replaces: 855998A09
Fits : 35-220 HP (1985-93) Mercury/Mariner Outboards
Side Fill Integral Trim/Tilt System w/ Square Style Eaton
w/ Design I, 3 Ram, 3 Wire Tilt/Trim Units w/ Side Fill
Fits: 200HP DFI, 225HP EFI & Carb, 225HP DFI,
Motor and 18-6273-1 Tilt/Trim Motor Pump Assy
Reservoir. Integral Trim/Tilt System
250 EFI, V-135, V-150, V-200, XR-6
TILT/TRIM ASSEMBLY
TILT/TRIM MOTOR
Replaces: 823653A5,
Replaces: 92975A28, A32
92459A4, 823653A9
To 1984 for Most Mercury Outboards
Fits:250,275 HP & V-3.4L, Serial No.5611648-UP
(Motor and Reservoir Only)
TRIM MOTOR
TRIM MOTOR
Replaces: 811628, 828708A1, 878265A6
Replaces: 828708, 878265A4
High-performance cartridge, replaceable motor. Design II,
For most late model Mercury/Mariner 1996 & UP (135,150,
Ram 3, 3 wire, tilt/trim units. Squared style Eaton
XR6 Mag III, 175, 200, 225, 250 HP -- 105 - 140 HP Jet)
TILT/TRIM MOTOR
Reference OE reservoir 811673 1
Contains: All parts necessary, a new 3- wire mo-
tor/reservoir, drive shaft coupler, oil seal,
O-ring and hardware.
For:
Models
Models
65
Jet
100
4-Cyl.
75
3-Cyl.
115
4-Cyl.
80
Jet
125
4-Cyl.
If you have this 3-wire single ram
system, use 18-6775
90
3-Cyl.
TILT/TRIM MOTOR
Replaces: 818903A1, 819762A4-A7, 819479A1, 819480A1,
81977A8-A9, 822870A1, 830250A3-T3, 832021A1-T4-A2-T2,
855654A1-T2, 19217A1-A5, 854472A2, A3, A4
Contains: All parts necessary, a new 2- wire motor/reservoir,
drive shaft coupler, oil seal, O-ring and hardware.
For:
Models
Models
30 Jet
60 3-Cyl., Bigfoot
30 4-Stroke
65 Jet
35
75 3-Cyl.
40 2, 3, 4-Cyl.
75 4-Stroke
40 4-Stroke, Bigfoot
80 Jet
45 4-Stroke, Bigfoot,
90 3-Cyl.
Bodensee
90 4-Stroke
50 3-Cyl.
100 4-Cyl.
50 4-Stroke, Bigfoot
115 4-Cyl.
309
If you have any of the 2-wire single systems, use 18-6777
55 3-Cyl.
125 4-Cyl.
