Sierra Marine Parts Catalog: Mercury Mariner
-- CONTAINS --
Part #
Desc.
O.E.#
Qty.
Face Seal and Tool
26-818575A2
1
Water Pump Base
To Face Plate Gasket
27-43033-1
1
Face Plate to Water
Pump Cover Gasket
27-817277
1
Sealing Washer
12-19183
1
Seal
26-45577
1
Oil Seal
26-76868
1
Oil Seal
26-16977
1
Oil Seal
26-89238
1
Oil Seal
26-81646-1
1
Oil Seal
26-12224
1
Oil Seal
26-14077
1
O-Ring
25-31534
1
O-Ring
25-48171
2
O-Ring
25-90011
1
O-Ring
25-21836
2
O-Ring
25-36318
2
LOWER UNIT SEAL KIT
Oil Seal
26-66302
2
Replaces: 26-816575A3
O-Ring
25-62702
1
-- CONTAINS --
Desc.
O.E.#
Qty.
Part #
Grommet
26-38970
1
Oil Seal
26-76868
2
Oil Seal
26-94038
1
Oil Seal
26-89236
1
Oil Seal
26-16977
1
Oil Seal
26-89238
1
Oil Seal
26-24590
1
Oil Seal
26-55682
1
Oil Seal
26-70081
1
Water Pump Base to
Gear Housing Gasket
27-85610-1
1
Water Pump Gasket
27-85608-1
1
Water Pump Gasket
27-85609-1
1
Rubber Washer
12-49221-1
1
O-Ring
25-25439
1
O-Ring
25-29976
1
O-Ring
25-30613
1
O-Ring
25-31534
1
O-Ring
25-32546
1
O-Ring
25-33145
1
O-Ring
25-30224
1
Water Pump Gasket
27-32438
1
LOWER UNIT SEAL KIT
O-Ring
25-30271
1
Replaces: 26-55682A1
Drain Screw Gasket
12-20260, 12-19183
2
-- CONTAINS --
Part #
Desc.
O.E.#
Qty.
Oil Seal
26-56788
1
Oil Seal
26-90562
1
Oil Seal
26-24590
1
Oil Seal
26-69188
1
Oil Seal
26-69189
1
Oil Seal
26-816464
1
Oil Seal
26-79831
1
Lower Water Pump Base
to Face Plate Gasket
27-32769
1
Upper Face Plate to
Pump Body Gasket
27-19551
1
Water Pump Base Gasket
27-32770
1
Water Pump Base Gasket
27-19552,
27-77417
1
Rubber Washer
12-49221-1
1
O-Ring
25-25439
1
O-Ring
25-26855
1
O-Ring
25-31986
1
LOWER UNIT SEAL KIT
O-Ring
25-26722
1
Replaces: 26-79831A1
Drain Screw Gasket
12-20260, 12-19183
2
-- CONTAINS --
Desc.
O.E.#
Qty.
Part #
Bushing Gasket
23-77631A2
1
Gasket
27-42631-1
1
Oil Seal
26-76868
2
Oil Seal
26-16977
1
Oil Seal
26-89238
1
Water Pump Gasket
27-85608-1
1
Water Pump Gasket
27-85609-1
1
Bushing
26-38970
1
O-Ring
25-31534
1
O-Ring
25-90011
1
O-Ring
25-29976
1
O-Ring
25-25439
1
Oil Seal
26-89236
1
LOWER UNIT SEAL KIT
O-Ring
25-30271
1
Replaces: 26-89238A2
Drain Screw Gasket
12-20260, 12-19183
2
385
APPLICATION BEGINS ON PAGE 387
