Sierra Marine Parts Catalog: Crusader
FLOAT
FLOAT
Replaces: 45303
FLOAT
(Alcohol Resistant)
(Alcohol Resistant)
(Alcohol Resistant)
Brass
Brass
Brass
CARBURETOR KIT AND FLOAT APPLICATION
Model or
Mfg.
Carb.
Carburetor
Carb.
Cyl.
Eng. Displacement
Code
Model
Number
Kit➀
Float
4
153" (2.5L)
R-2
2GC
7025082, 7028086
6
225" (3.7L)
R-2
2GC
7025181
--
8
283" (4.6L), 327 (5.3L)
R-2
2GC
7024185
--
8
283" (4.6L)
C-1
YH
2618, 2912
--
8
305" (5.0L)
R-2
2GV
17057134
8
327" (5.3L), 409 (6.6L)
R-4
4GC
7020084, 085
--
8
327" (5.3L), 409 (6.6L)
R-4
4GC
7023084, 085, 089
--
8
348" (5.7L)
C-4
AFB
2955
--
8
350" (5.7L), 454 (7.4L)
R-4
4MV
17059293, 17082403
8
427" (7.0L)
R-4
4MV
7027081, 7028282
➀ Does Not Include Metering Rods
FUEL LINE HOSE
FUEL LINE HOSE
UNIVERSAL
UNIVERSAL
For fuel pump to carburetor connection. Replaces
For fuel pump to carburetor connection. Replaces
copper or steel tubing 3/8" X 31" PTFE composite
copper or steel tubing 3/8" X 25" PTFE composite
hose with 5/8"-18 male inverted flare straight one
hose with 5/8"-18 male inverted flare straight one
end, 5/8"-18 90� one end. SAE J1527 type A1
end, 5/8"-18 90� one end. SAE J1527 type A1
FUEL PUMP
Replaces: 32722
FLAME ARRESTOR
FLAME ARRESTOR
(Flange I.D. #6790, M3530)
Replaces: 97595, 97214
Replaces: 33628
For: GM (4 & 6 Cyl.) 153, 230, 250, 292
V-8
Hi-Performance
FUEL PUMP
(Flange I.D. #41415, M6948)
FUEL PUMP
For: GM (V-8) 305, 307, 350, 400
FUEL PUMP
(Flange I.D. #40155)
(5.25 - 6.5 PSI)
(Flange I.D. #41414)
519
For: GM (V-8) 283, 307, 327, 350, 409
Dual Diaphragm - Requires Sight Glass
For: Ford (V-8) 302
