Sierra Marine Parts Catalog: Crusader
SIERRA MANIFOLDS
ARE PAINTED, PACKAGED AND LEAK TESTED
MANIFOLD
MANIFOLD
Port & Starboard
Port & Starboard
Replaces: Barr FM-1-83
Replaces: Barr CHV-1-83
Universal Center Riser Manifold
Universal Center Riser Manifold
FITS:
FITS:
302 and 351 CID engines
283 and 327 CID engines thru 1964; 305, 307
Comes with 18-4363 Mounting Package
and 350 CID engines 1965 and later
Use with:
Use with:
Exhaust Manifold Gasket Set: 18-0603
Exhaust Manifold Gasket Set: 18-0604
*For Exploded View - See Pages 560-561
*For Exploded View - See Pages 558-559
ELBOW
MANIFOLD
Replaces: Barr 20-0082
Port & Starboard
Comes with 18-4364 open
Replaces: Crusader 98125
If blocked mounting kit is required use 18-8535
Use with:
Use:
Exhaust Manifold Gasket: 18-0418
Riser Gasket: 18-2854 open
For: GM Big Block V-8 454-502 ci
MANIFOLD
MANIFOLD
Starboard
Port & Starboard
Replaces: Crusader 97992, 97114
Replaces: Crusader 98243
Crusader GM Big Block V8 454cu.in.
(Models: CH350 and 454XL)
Use with:
Use with:
Exhaust Manifold Gasket: 18-2949
Exhaust Manifold Gasket: 18-0418
Mounting Kit: 18-8545
Mounting Kit: 18-8524
For: GM Small Block V-8 305-351 ci
MANIFOLD
MANIFOLD
Starboard
Port
Replaces: Crusader 97752, 96120
Replaces: Crusader 97993, 97115
Crusader GM Small Block V8 305-350cu.in.
Crusader GM Big Block V8 454cu.in.
(Models: 220 and 270)
(Models: CH350 and 454XL)
Use with:
Use with:
Exhaust Manifold Gasket: 18-2949
Exhaust Manifold Gasket: 18-0418
Mounting Kit: 18-8521
Mounting Kit: 18-8524
MANIFOLD
MANIFOLD
Port & Starboard
Port
Replaces: Barr CHVA-1-84,
Replaces: Crusader 97753, 96121
Marine Power 0991-110
Crusader GM Small Block V8 305-350-cu.in.
Fits 454 cu.in. GM big block V8 engines
(Models: 220 and 270)
Use with:
Use with:
Exhaust Manifold Gasket: 18-0418
Exhaust Manifold Gasket: 18-2949
530
*For Exploded View - See Pages 556-557
Mounting Kit: 18-8521 (if manifold has alternator bracket)
