Sierra Marine Parts Catalog
OIL FILter QuIck-reFerence GuIde
MerCruiser -
Continued
Model
Cylinders
CID / Litre
Year
Oil Filter
replaces
Crankcase Capacity
recommended Oil
4.3L / LX / LH / LXH
V6
264 / 4.3L
1988 - 2001
35-883702
4.3L / 4.5 Qt.
25W-40 FC-W
4.3L
V6
265 / 4.3L
2002 - 2010
35-883702
4.3L / 4.5 Qt.
25W-40 FC-W
4.3L EFI
V6
266 / 4.3L
1998 - 2001
35-883702
4.3L / 4.5 Qt.
25W-40 FC-W
4.3L MPI
V6
267 / 4.3L
2002 - 2010
35-883702
3.8L / 4.0 Qt.
25W-40 FC-W
4.3L MPI (Catalyzed)
V6
268 / 4.3L
2011 - Current
35-866340K01
3.8L / 4.0 Qt.
20W-40 Synthetic Catalyst (1)
*NOTE: V6 engines equipped with the oil filter relocation option will use filter 18-7824.
190
V8
283 / 4.6L
1963 - 1964
35-866340K01
4.7L / 5.0 Qt.
25W-40 FC-W
198
V8
305 / 5.0L
1977 - 1988
35-99894
5.7L / 6.0 Qt.
25W-40 FC-W
200
V8
305 / 5.0L
1985 - 1987
35-866340K01
4.7L / 5.0 Qt.
25W-40 FC-W
215 (Ford)
V8
302 / 5.0L
1970 - 1972
35-802886
6.6L / 7.0 Qt.
25W-40 FC-W
225 (Ford)
V8
302 / 5.0L
1973 - 1974
35-802886
5.7L / 6.0 Qt.
25W-40 FC-W
225
V8
327 / 5.4L
1963 - 1966
35-866340K01
4.7L / 5.0 Qt.
25W-40 FC-W
225
V8
327 / 5.4L
1967 - 1969
35-866340K01
6.6L / 7.0 Qt.
25W-40 FC-W
228
V8
305 / 5.0L
1977 - 1978
35-866340K01
4.7L / 5.0 Qt.
25W-40 FC-W
230
V8
305 / 5.0L
1985 - 1987
35-866340K01
5.2L / 5.5 Qt.
25W-40 FC-W
V8
351 / 5.8L
1975 - 1977
35-802886
4.7L / 5.0 Qt.
25W-40 FC-W
233 (Ford)
233 (Ford) Inboard
V8
351 / 5.8L
1973 - 1976
35-802886
6.6L / 7.0 Qt.
25W-40 FC-W
250
V8
327 / 5.4L
1969
35-99894
6.6L / 7.0 Qt.
25W-40 FC-W
250
V8
327 / 5.4L
1968
35-99894
5.7L / 6 Qt.
25W-40 FC-W
250
V8
350 / 5.7L
1975 - 1977
35-99894
4.7L / 5.0 Qt.
25W-40 FC-W
255
V8
350 / 5.7L
1975 - 1977
35-99894
4.7L / 5.0 Qt.
25W-40 FC-W
255 (Ford)
V8
351 / 5.8L
1973 - 1974
35-802886
4.7L / 5.0 Qt.
25W-40 FC-W
255 (Ford) Inboard
V8
351 / 5.8L
1973 - 1976
35-802886
6.6L / 7.0 Qt.
25W-40 FC-W
260
V8
350 / 5.7L
1975 - 1987
35-866340K01
5.2L / 5.5 Qt.
25W-40 FC-W
270
V8
350 / 5.7L
1969 - 1972
35-99894
6.6L / 7.0 Qt.
25W-40 FC-W
280 TRS
V8
350 / 5.7L
1975 - 1976
35-99894
6.0L / 6.5 Qt.
25W-40 FC-W
300 Tempest
V8
350 / 5.7L
1985 - 1986
35-99894
6.0L / 6.5 Qt.
25W-40 FC-W
320 EFI
V8
350 / 5.7L
1987 - 1989
35-866340K01
6.0L / 6.5 Qt.
25W-40 FC-W
325
V8
427 / 7.0L
1969 - 1972
35-99894
7.6L / 8.0 Qt.
25W-40 FC-W
325 Inboard
V8
427 / 7.0L
1968 - 1974
35-866340K01
6.6L / 7.0 Qt.
25W-40 FC-W
330
V8
454 / 7.4L
1977 - 1981
35-99894
5.7L / 6.0 Qt.
25W-40 FC-W
330
V8
454 / 7.4L
1982 - 1987
35-866340K01
6.6L / 7.0 Qt.
25W-40 FC-W
350 Mag.
V8
350 / 5.7L
1986 - 1997
35-866340K01
5.2L / 5.5 Qt.
25W-40 FC-W
350 Mag. EFI
V8
350 / 5.7L
1996 - 1997
35-866340K01
5.2L / 5.5 Qt.
25W-40 FC-W
350 Mag. MPI
V8
350 / 5.7L
1996 - 2001
35-866340K01
5.2L / 5.5 Qt.
25W-40 FC-W
350 Mag. MPI
V8
350 / 5.7L
2002 - 2010
35-866340K01
4.25L / 4.5 Qt.
25W-40 FC-W
350 Mag. MPI (Catalyzed)
V8
350 / 5.7L
2011 - Current
35-866340K01
4.25L / 4.5 Qt.
20W-40 Synthetic Catalyst (1)
370 TRS
V8
454 / 7.4L
1978 -1987
35-866340K01
5.7L / 6.0 Qt.
25W-40 FC-W
377 Scorpion
V8
377 / 6.2L
1997 - 2010
35-866340K01
4.7L / 5.0 Qt.
25W-40 FC-W
390
V8
482 / 7.9L
1969 - 1970
35-99894
7.6L / 8.0 Qt.
25W-40 FC-W
390 Inboard
V8
482 / 7.9L
1969 - 1970
35-99894
6.6L / 7.0 Qt.
25W-40 FC-W
400 TRS
V8
454 / 7.4L
1978 - 1987
35-866340K01
6.6L / 7.0 Qt.
25W-40 FC-W
420
V8
454 / 7.4L
1987 - 1989
35-866340K01
5.7L / 6.0 Qt.
25W-40 FC-W
425
V8
454 / 7.4L
1990 - 1993
35-866340K01
7.6L / 8.0 Qt.
25W-40 FC-W
440 TRS Cyclone
V8
454 / 7.4L
1983 - 1986
35-99894
6.6L / 7.0 Qt.
25W-40 FC-W
450
V8
454 / 7.4L
1995 - 1996
35-99894
7.6L / 8.0 Qt.
25W-40 FC-W
454 Mag. Alpha
V8
454 / 7.4L
1986 - 1988
35-866340K01
6.6L / 7.0 Qt.
25W-40 FC-W
454 Mag.
V8
454 / 7.4L
1989 - 1991
35-866340K01
7.6L / 8.0 Qt.
25W-40 FC-W
454 Mag.
V8
454 / 7.4L
1992 - 1997
35-866340K01
6.6L / 7.0 Qt.
25W-40 FC-W
454 Mag. EFI
V8
454 / 7.4L
1994 - 1996
35-866340K01
6.6L / 7.0 Qt.
25W-40 FC-W
454 Mag. MPI
V8
454 / 7.4L
1996 - 2001
35-866340K01
6.6L / 7.0 Qt.
25W-40 FC-W
460 TRS
V8
482 / 7.9L
1983 - 1986
35-99894
9.4L / 10 Qt.
25W-40 FC-W
465
V8
502 / 8.2L
1990 - 1994
35-866340K01
7.6L / 8.0 Qt.
25W-40 FC-W
496 Mag.
V8
496 / 8.1L
2001 - 2010
35-866340K01
8.5L / 9.0 Qt.
25W-40 FC-W
All listed oil capacities are approximate amounts only and may or may not include the oil filter capacity.
990
ALWAYS follow proper crankcase drain and fill procedures. Check engine dipstick for proper crankcase oil level.
