21
®
HYDRAULIC STEERING KIT OVERVIEW:
BAYSTAR HK4200A-3
The kit contains the following:
1- HH4314-3
BayStar Helm 1.4 cu" (22.94cc)
1- HC4645H*
BayStar Compact Cylinder
1- HT4420H
20 ft. tubing kit - cut to length
2- HA5430
Hydraulic Oil (1 Liter)
APPLICATIONS:
BayStar is for single-outboard powered boats rated up to 150 HP,
including runabouts and inflatables — and outboard engines with
ABYC standard engine tilt tubes up to 150 HP (total). For single
station, single engine use only.
BayStar is not intended for high speed, high performance type
boats, such as Bass Boats.
5.0 steering wheel turns lock-to-lock
*Some engines may require alternative cylinders that require high precision steering.
STEERING - Hydraulic Kit Overview
SEASTAR HK6400A-3
The kit contains the following:
1- HH5271-3
SeaStar Helm 1.7 cu" (27.80cc)
1- HC5345-3*
SeaStar Pivot Cylinder
2- HA5430
Hydraulic Oil (1 Liter)
SeaStar kit HK63xx-3 (featured right) includes HK6400A-3 and
hoses.
APPLICATIONS:
Single and dual non-power-assisted outboard engines up to 350
HP (700 combined HP for counter-rotating duals) that have ABYC
standard engine tilt tube.
Ideal for cruisers, runabouts, center console boats, offshore fishing
boats and many more. Suitable for speeds up to 60 MPH and dual
station use (with purchase of extra helm, hose & fittings). Allows
independent engine tilt in dual engine installations. Dual engines
require purchase of a tie bar kit and extra hardware.
5 steering wheel turns lock-to-lock
HK63xxA-3
Shown
SEASTAR PRO HK75XXA-3
The kit contains the following:
1- HH5770-3
SeaStar Helm 2.0 cu" (32.77cc)
1- HC6345-3*
SeaStar Pro Pivot Cylinder
2- HA5430
Hydraulic Oil (1 Liter)
APPLICATIONS:
Seastar Pro is for high-performance boats with single non-power-
assisted outboards up to 350 HP, especially those capable of
speeds over 60 MPH, which demand maximum steering control
and comfort. It is suitable for use with high-performance propellors
and jack plates.
4.15 steering wheel turns lock-to-lock
HK75xxA-3
Shown
See Page 148
