214
®
*
Proprietary ball joint type cable adapter kit required to complete connection to the engine. This part (formerly SeaStar Solutions P/N
CA27019P) is no longer available from SeaStar Solutions. Please consult with Mercury Marine for more information about Chrysler and early
model Force engines using this type of cable connection.
** Cable adapter kits listed are required to complete connection to the engine. Consult engine manufacturer, dealer or distributor if kit is not listed.
CONTROL CABLE OPTIONS BASED ON ENGINE TYPE:
STANDARD GRADE
STANDARD GRADE
USING ENG. MFR. CONTROLS
USING AFTMKT. CONTROLS
Chrysler®
+ ball joint kit*
CC230xx + ball joint kit*
Force® pre-1993
+ ball joint kit*
CC230xx + ball joint kit*
Force®
1993-date
CC179xx (600A type)
Johnson®/Evinrude® 1979-date
CC205xx (479 type)
Johnson®/Evinrude® pre-1979
CC170xx (400 type)
Mariner®
40 HP & below pre-1993
CC210xx (630 type)
Mariner®
40 HP & below 1993-date
CC179xx (600A type)
Mariner®
all above 40 HP
CC179xx (600A type)
Mercury®
1965-date
CC179xx (600A type)
Mercury®
products 2003-date
(4000 series Gen II controls)
CC189xx (Gen II type)
N/A
Honda®, Nissan®, Suzuki®, Tohatsu® , Yamaha®
Chrysler®, All Inboards
MerCruiser® All Stern Drives (except 4000 series controls) CC179xx (600A type)
MerCruiser® 2003-date (using 4000 series controls)
CC189xx (Gen II type)
N/A
Mercury® All Inboards (except 4000 series controls)
CC179xx (600A type)
Mercury® Inboards 2003-date (using 4000 series controls) CC189xx (Gen II type)
N/A
OMC® 1979-date
CC205xx (479 type)
OMC® pre-1979
CC170xx (400 type)
Volvo® using Volvo® controls
Volvo® using OMC® controls
N/A
N/A
Volvo® Turbo, SX, new-gen OMC drives w/OMC® controls N/A
N/A
Others
1/4-28 terminal, 1 bulkhead, 1 clamp fitting (43BC)
(see Premium Grade)
(see Premium Grade)
1/4-28 terminal, 2 clamp fittings (43C)
(see Premium Grade)
(see Premium Grade)
5/16-24 terminal, 1 bulkhead, 1 clamp fitting (64BC)
(see Premium Grade)
(see Premium Grade)
5/16-24 terminal, 2 clamp fittings (64BC)
(see Premium Grade)
(see Premium Grade)
Mercury® Sport Jet 90 & 120 (throttle cable)
Mercury® Sport Jet 90 & early 120 (gate cable)
Mercury® Sport Jet 175 (gate cable)
N/A
N/A
OMC® Turbo Jet (throttle control cable)
CC205xx (479 type)
OMC® Turbo Jet (gate control cable)
N/A
N/A
OUTBOARD ENGINES:
STERNDRIVE (I/O) AND SOME INBOARDS:
HEAVY DUTY APPLICATIONS, INCLUDING SOME INBOARD & JET ENGINES:
JET ENGINES (MERCURY SPORT JET®, OMC TURBO JET® & SIMILAR):
CONTROL CABLES - Selection Guide
