77
®
THE RACK MECHANICAL RACK
STEERING SYSTEM:
Traditional SeaStar Solutions mechanical steering is
still the choice for sterndrives, inboards and other
power assisted applications. It’s just right for power
steered boats in which No FeedBack™ systems are
not required. Our Rack features the precision and
comfort of four turns lock-to-lock with a cable and
helm that install easily from behind the dash. In single
cable configurations, this is the best 4-turn choice for
power-steered boats.
APPLICATIONS:
Virtually all power-assisted sterndrive boats with
wheels up to 16” diameter.
Back Mount Rack Replaces 1984-date SeaStar
Solutions “The Rack” steering without dash
modification. (Requires use of SSC134xx Back Mount
or SSC154xx XTREME Rack cable.)
For single station use only. Components are available
for dual cable systems, but we recommend No-
FeedBack steering for all dual cable steered, non-
power-assisted outboards and sterndrives. See the
NFB Pro Rack Dual Cable and SeaStar PRO Hydraulic
sections of this catalog.
FEATURES:
Precise, easy 4 turns lock-to-lock.
Kits include: cable, helm, 90° bezel and hardware.
Standard 3/4” round tapered steering shaft.
Stainless steel cable output ends.
Fast, easy installation: back mount design allows
quick placement in dash PLUS mounting hardware
fits SeaStar Solutions rack holes.
Meets A.B.Y.C. standards.
Meets N.M.M.A. certification requirements.
Made, designed and assembled in the USA.
P/N SSC134xx
(single cable)
(Steering Wheel
not included.)
THE RACK
SINGLE CABLE SYSTEM
COMPLETE SYSTEM
BM Rack Steering Kit (single cable)
COMPONENTS
Back Mount Rack Helm (single/dual)
Back Mount Rack Single Cable
Back Mount Bezel (90°)
OPTIONS
BM Rack Tilt Dash Module
Each Kit Includes Tilt Helm & Tilt Mechanism
BM Rack Tilt Helm (single/dual)
Sport Tilt Mechanism
Sport Plus Tilt Mechanism
Rack Single Cable
Dash Wedge Kit (10°)
Dash Wedge Kit (20°)
Back Mount Rack Friction Device
(Old #3953114P)
Cable Gard (fits most tilt tubes)
SERVICE ITEMS
Back Mount Rack Dual Cable
Steering Wheel Hardware Kit
(Old #2745417P)
* Requires tilt mechanism to complete Tilt Steering system installation.
†
For dual rack & pinion steered boats. If steering is NOT
power-assisted, upgrading to NFB 4.0 Pro Rack is recommended.
STEERING - Inboard (Mechanical)
