ORDERING GUIDE: SEASTAR 2-LINE INBOARD STEERING
ENGINE/CYLINDER
QTY.
CONFIGURATION
COMPONENT DESCRIPTION
REQ’D
MODEL
PART NO.
SYSTEM #1
CYLINDER
1
BA125-7ATM
NUMBER OF TURNS: 4.0
HELM
1
SEASTAR 1.7 *
**Ships with HK4410-3 Kit
TUBING (SEE NOTES 1 & 3)
3/8” DIA. NYLON
HT5xxx
OIL
3
SEASTAR OIL (QT.)
FOR EXTRA STEERING STATION, ADD:
HELM
1
SEASTAR 1.7 *
FITTING KIT
1
ADD A STATION
EXTRA TUBING (SEE NOTES 1 & 3)
3/8” DIA. NYLON
HT5xxx
OIL
1
SEASTAR OIL (QT.)
SYSTEM #2
CYLINDER
1
BA135-7ATM
NUMBER OF TURNS: 5.0
HELM
1
SEASTAR 1.7 *
**Ships with HK4420-3 Kit
TUBING (SEE NOTES 1 & 3)
3/8” DIA. NYLON
HT5xxx
OIL
3
SEASTAR OIL (QT.)
FOR EXTRA STEERING STATION, ADD:
HELM
1
SEASTAR 1.7 *
FITTING KIT
1
ADD A STATION
EXTRA TUBING (SEE NOTES 1 & 3)
3/8” DIA. NYLON
HT5xxx
OIL
1
SEASTAR OIL (QT.)
SYSTEM #3
CYLINDER
1
BA150-7ATM
NUMBER OF TURNS: 6.0
HELM
1
SEASTAR 1.7 *
TUBING (SEE NOTES 1 & 3)
3/8” DIA. NYLON
HT5xxx
OIL
3
SEASTAR OIL (QT.)
FOR EXTRA STEERING STATION, ADD:
HELM
1
SEASTAR 1.7 *
FITTING KIT
1
ADD A STATION
EXTRA TUBING (SEE NOTES 1 & 3)
3/8” DIA. NYLON
HT5xxx
OIL
1
SEASTAR OIL (QT.)
SYSTEM #4
CYLINDER
1
BA150-7TM
NUMBER OF TURNS: 4.25
HELM
1
SEASTAR 2.4 *
TUBING (SEE NOTES 1 & 3)
3/8” DIA. COPPER
HOSE KIT
1
SEASTAR HOSE KIT
OIL
3
SEASTAR OIL (QT.)
FOR EXTRA STEERING STATION, ADD:
HELM
1
SEASTAR 2.4 *
FITTING KIT
1
ADD A STATION
EXTRA TUBING (SEE NOTES 1 & 3)
3/8” DIA. COPPER
OIL
1
SEASTAR OIL (QT.)
SYSTEM #5
CYLINDER
1
BA175-7TM
NUMBER OF TURNS: 5.5
HELM
1
SEASTAR 2.4 *
TUBING (SEE NOTES 1 & 3)
3/8” DIA. COPPER
HOSE KIT
1
SEASTAR HOSE KIT
OIL
3
SEASTAR OIL (QT.)
FOR EXTRA STEERING STATION, ADD:
HELM
1
SEASTAR 2.4 *
FITTING KIT
1
ADD A STATION
EXTRA TUBING (SEE NOTES 1 & 3)
3/8” DIA. COPPER
OIL
1
SEASTAR OIL (QT.)
OPTIONAL EQUIPMENT
BACK PLATE KIT
(FOR STANDARD HELMS)
20 DEGREE WEDGE
(FOR STANDARD HELMS)
AUTOPILOT FITTING KIT
(FOR ALL HELMS)
(Tube)
POWER ASSIST STEERING
* Many helm styles available, See Page 132-133 for Options
1. For systems 1, 2 & 3 – nylon tubing
(3/8" dia.) is the standard requirement
for plumbing the system. Copper tubing
(3/8" dia.) can be substituted but Fitting Kit
HF5507 is required.
2. For systems 4 & 5 – copper tubing
(3/8" dia.) is the standard requirement for
plumbing the system. Fitting Kit HF5508 is
required.
3. For systems 1, 2, 3, 4, & 5 – Seastar
outboard hose can be substituted for
nylon or copper tube. These hoses must be
ordered in standard lengths. They cannot be
cut to length.
STEERING - Inboard (Hydraulic)
