SeaStar Autopilot Pump
| CSS Drop Down Menu by PureCSSMenu.com | < Previous Page|Next Page > |
89
®
TECHNICAL SPECIFICATION
Voltage
12 or 24 volts
Fittings
Compatible w/ Standard SeaStar Hoses (HO51xx etc)
WIRE DETAILS
Length
24”
Gauge
12 awg
Connector
None - Bare Leads
Oil Compatibility
SeaStar Steering Fluid
Weight
4.9 lbs (2.2 kg)
Autopilot Pump Sizes
Type 1: 60 in
3
/min (no-load)
Type 2: 100 in
3
/min (no-load)
Maximum Pressure
1000 psi
Typical Current Draw
12V Type 1: 4 – 8 amps
(Depending on Application)
12V Type 2: 5 – 11 amps
24V Type 1: 2 – 4 amps
24V Type 2: 3 – 6 amps
AUTOPILOT PUMP CYLINDER CAPACITY
Type 1
4.9 in
3
- 12.5 in
3
Type 2
12.5 in
3
- 21 in
3
SEASTAR AUTOPILOT PUMP:
The SeaStar Autopilot pump is a high efficiency,
fixed flow, reversible type Pump set producing very
little vibration or noise. It is offered in 12 and 24
volt configurations, as well as two different pump
sizes (type 1 & type 2). It can be used as a stand
alone pilot pump or can be mounted to a previously
installed SeaStar Power Assist unit and can prevent
the need to break into the hydraulic lines.
FEATURES:
Long life DC Motor (i.e. long life brushes).
Compact design.
Simplified installation.
Low power consumption.
ABYC, CE and J1171 compliant.
Superior corrosion resistance.
Quiet operation.
Mounting bracket included.
Stand alone or mounts to SeaStar Power
Assist unit.
Replaces other 12 & 24 volt pumps.
COMPLETE SYSTEM
Type 1 - 12V - 60cu"/min
Type 2 - 12V - 100cu"/min
Type 1 - 24V - 60cu"/min
Type 2 - 24V - 100cu"/min
OPTIONS
SPA Retrofit kit
Add a Station kit
Nylon Return Line Required
Additional Steering Hose Required
Stand alone pilot pump - can be retrofit to
a PA unit
STEERING - Inboard (Hydraulic)
See Page 148
