Hynautic Heavy Duty Trim Tabs (Cont.)
| CSS Drop Down Menu by PureCSSMenu.com | < Previous Page|Next Page > |
99
®
SPECIFICATIONS
Trim Cylinder Assembly:
Model TK-01
STROKE = 4"
DISPLACEMENT =
5.94 in.(3)
FORCE = 2,230 LB. @ rated pressure
CONSTRUCTION = Brass/Bronze
DIMENSIONS:
Base = 7.13" X 3.75"
Cylinder = 14.0" Retracted
HYNAUTIC HEAVY DUTY TRIM TAB ORDERING GUIDE:
TCS-1-01 2-CYLINDER SYS, 24 VOLT:
Control switch
1 ea
Tab cyl. - cruiser
2 ea
Power pump
2 ea
Manual
1 ea
Hose - 2 ft.
4 ea
TCS-1-02 2-CYLINDER SYS, 12 VOLT:
Control switch
1 ea
Tab cyl. - cruiser
2 ea
Power pump
2 ea
Manual
1 ea
Hose - 2 ft.
4 ea
TCS-2-02 4-CYLINDER SYS, 12 VOLT:
Control switch
1 ea
Tab cyl. - cruiser
4 ea
Junct. blk. ftg.
2 ea
Power pump
2 ea
Manual
1 ea
Hose - 2 ft.
12 ea
OPTIONAL PUMP:
Pump 24VDC
SYSTEM PERFORMANCE
(Full Extension Time)
(System Number in parenthesis)
No. Cylinders
Pump Models
per plane
1
6.28 sec.
4.46 sec.
-
(TCS-1-02)
(TCS-1-01)
2
12.96 sec.
8.91 sec.
6.48 sec.
(TCS-2-02)
(TCS-2-01)*
(TCS-3-03)*
3
19.44 sec.
13.38 sec
9.72 sec
(TCS-3-02)*
(TCS-3-01)*
(TCS-3-03)*
4
-
17.82 sec.
12.96 sec.
(TCS-4-01)*
(TCS-4-03)*
Order the system number in parenthesis.
Pump Assembly:
Model
DISPL
(in.3/min.)
57
80
110
MOTOR
12VDC
24VDC
24VDC
APPLICATIONS:
The Hynautic cruiser trim system is designed for yachts and commercial vessels. One brass trim cylinder provides
a force equal to approximately 2.5 times that of the typical nylon cylinders.
Therefore, a Hynautic TCS-1-02 trim system, which includes separate port and starboard cylinder/
pump assemblies is effective for most yachts to 65 feet using properly reinforced stainless planes. When
more hydraulic muscle is needed, two cylinders per tab may be pressurized from a single pump as in the
TCS-2-01 system.
Similarly, Hynautic can supply a system as complex as four cylinders moving a single trim plane from a single
power pump source.
Because of the diversity of tab shapes and materials, the design is left to the builder and not included in the
basic system.
HYNAUTIC - Trim Tabs
