STEERING
HYDRAULIC HELM PUMP -Q/S
HYDRAULIC HELM PUMP -Q/S-TILT
Front Mount 1.5 cu in displacement. Approximately 5 turns lock to lock on singles
Front Mount 1.5 cu in displacement. Approximately 5 turns lock to lock for singles
and 10 on dual cylinders
and 10 on dual cylinders
Compact design
Compact design
Built‑in valve for positive rudder lock
Tilt Range of 48 Deg and 5 locking positions
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 175‑4 stroke engines
Hydraulic Steering for Verado 135 to 175‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can
be used on OptiMax with Mercury hydraulic cylinder and hoses Also can be used
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can
on 75‑115 4 stroke and 1.5L opti 75‑115 HP
be used on OptiMax with Mercury hydraulic cylinder and hoses Also can be used
on 75‑115 4 stroke and 1.5L opti 75‑115 HP
HYDRAULIC HELM PUMP -Q/S
HYDRAULIC STEERING KIT -Q/S
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (14 ft)
Approximately 5 turns lock to lock on a single engine
Front Mount 2.0 cu in displacement. Approximately 4 turns lock to lock on singles
Hydraulic Steering ‑ 75 HP engines and above
and 8 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Quicksilver 1.5 cu in displacement Std Helm kit with Cylinder and Hoses. (16 ft)
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
Approximately 5 turns lock to lock on a single engine
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
Hydraulic Steering ‑ 75 HP engines and above
Front Mount 2.4 cu in displacement. Approximately 3 turns lock to lock on singles
Quicksilver 1.5 cu in displacement Std Helm kit with Cylinder and Hoses. (18 ft)
and 6.5 on dual cylinders
Approximately 5 turns lock to lock on a single engine
Compact design
Hydraulic Steering ‑ 75 HP engines and above
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
Quicksilver 1.5 cu in displacement Std Helm kit with Cylinder and Hoses. (20 ft)
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above
Quicksilver 1.5 cu in displacement Std Helm kit with Cylinder and Hoses. (22 ft)
Approximately 5 turns lock to lock on a single engine
Hydraulic Steering engines 75 HP and above
Quicksilver 1.5 cu in displacement Std Helm kit with Cylinder and Hoses. (24 ft)
Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above
US Quicksilver Product Guide
291
