STEERING
HYDRAULIC HELM PUMP -Q/S-TILT
TIE BAR- SINGLE CYLINDER DUAL ENGINE
Front Mount 2.0 cu in displacement. Approximately 4 turns lock to lock on singles
This tie bar can be used on a dual installation with just one cylinder. 26 inch length
and 8 on dual cylinders
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
Compact design
cylinder Verado and Opti Max . Use only with Mercury cylinders for dual engine
Tilt Range of 48 Deg and 5 locking positions
applications
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
This tie bar can be used on a dual installation with just one cylinder. 28 inch length
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
cylinder Verado and Opti Max . Use only with Mercury cylinders for dual engine
applications
Front Mount 2.4 cu in displacement. Approximately 3 turns lock to lock on singles
and 6.5 on dual cylinders
Compact design
This tie bar can be used on a dual installation with just one cylinder. 30 inch length
Tilt Range of 48 Deg and 5 locking positions
Built‑in valve for positive rudder lock
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
Integral relief valve for over pressure protection
cylinder Verado and Opti Max . Use only with Mercury cylinders for dual engine
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
applications
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
REMOTE FILL KIT FOR HYDRAULIC STEERING
This tie bar can be used on a dual installation with just one cylinder. 32 inch length
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 & above), 150 4 Stroke, 135‑200 4
cylinder Verado and Opti Max . Use only with Mercury cylinders for dual engine
applications
This tie bar can be used on a dual installation with just one cylinder. 34 inch length
75‑115 HP EFI 4 Stroke OB (s/n 1B366823 and above), 150 4 Stroke, 135‑200 4
cylinder Verado and Opti Max . Use only with Mercury cylinders for dual engine
applications
TIE BARS - DUAL ENGINES
Remote fill adapter for rear mount and tilt mount Hydraulic pumps
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
ADAPTER FOR POWER PURGE
26 Inches long
Outboard centerline spacing of 66.0 cm (26 in.)
For use with the 75‑115 hp EFI FourStroke outboard (s/n 1B366823 & above) and
the 135‑200 Verado‑ V6 OptiMax‑ Up to 600 HP dual Install with one Counter
Rotation Engine
28 Inches long
Adapter for the Power Puge system
Outboard centerline spacing of 71.1 cm (28 in.)
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
For use with the 75‑115 hp EFI FourStroke outboard (s/n 1B366823 & above) and
the 135‑200 Verado‑ V6 OptiMax‑ Up to 600 HP dual Install with one Counter
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
Rotation Engine
292
