SHIELDS FUEL FILL HOSE
Shields Fire � Acol � Fuel Fill Hose resists
gasoline/alcohol blends and is compounded for
low permeation. It is abrasion resistant and it
is reinforced with wire helix imbedded between
piles of HD synthetic cord. This imported hose
is primarily used for fuel fill (gas or diesel) and
is for pleasure boats only. It meets SAE J1527
Type A2 and ISO 7840 Type A2 NMMA/CE Type
Accepted standards.
Burst
Wt.
50' (15.2m)
12 1/2' (3.8m)
12 1/2' (3.8m)
10' (3.1m)
10' (3.1m)
25' (7.6m)
I.D.
mm
O.D.
mm
Ply Pressure
"C"
Coils Code #
Length Code #
Carton Code # Length Code # Carton Code # Length Code #
1 /2"
38.1 1 /64"
1
57
16-355-1120
16-355-1124
16-355-1124BX
16-355-1123 16-355-1123BX
16-355-1125
48.0
2
90#
77
--
51 2 31/64"
16-355-2000
16-355-2004
16-355-2004BX
16-355-2003 16-355-2003BX
2"
63.1
2
90#
111
SHIELDS FIRE-ACOL 15 LOW
PERMEATION FUEL HOSE
Shields Fire-Acol 15 � Low Permeation
Fuel Hose has a special design NBR tube
with an embedded plastic barrier layer to
prevent permeation. The design of this
hose provides easy coupling insertion
and the NBR/PVC cover is weather and
UV resistant. The hose is also polyester
reinforced and fire-resistant. This hose is
primarily used for fuel feed (gasoline up to
85% ethanol blended fuels/diesel/bio-diesel
all blends). The temperature range is -20�F
to 212�F.
2 YEAR
EMISSION
PERFORMANCE
WARRANTY
This hose complies with EPA and CARB very low
Bulk Pack
Max
Wt.
250' reel
50' R/O Ctn.
10' Polypac
permeation requirements. It meets USCG Type
I.D.
mm
O.D.
mm
WP
C
Code #
Code #
Code #
/64" 19.3 100 22
49
A1-15 requirements for pleasure boats, SAE J1527
/8" 9.5
3
16-365-0380
16-365-0386
16-365-0383
/2" 12.7
/32" 22.86 100 27
1
29
16-365-0120
16-365-0126
16-365-0123
Type A1-15, ISO 7840 Type A1, and NMMA/CE Type
accepted standards
82
