SHIELDS LOW PERMEATION MARINE FUEL HOSE
2 YEAR
EMISSION
PERFORMANCE
WARRANTY
Shields Low Permeation Marine Fuel Hose
has a plastic barrier veneer with an NBR outer
layer tube to prevent permeation. This poly-
ester reinforced hose complies with EPA and
CARB very low permeation requirements and
is weather/UV resistant. This hose is primarily
used for fuel feed (gasoline up to 85% ethanol
blended fuels/diesel/all bio-diesel blends). It
meets USCG Type A1 � 15 requirements for
pleasure boats and meets SAE J1527 Type
A1-15, ISO 7840 Type A1, and NMMA/CE type
accepted standards. The temperature ranges
from -20�F to 212�F.
Bulk Pack
Max
Wt.
250' reel
50' R/O Ctn.
25' R/O Ctn
10' Polypac
I.D.
mm
O.D.
mm
WP
C
Code #
Code #
Code #
Code #
16-368-0140
16-368-0146
16-368-0145
16-368-0143
/4" 6.4
13.72
100
11
/64"
1
35
16-368-0560
16-368-0566
16-368-0565
16-368-0563
/16" 7.9
15.49
100
13
/8"
5
5
16-368-0380
16-368-0386
16-368-0385
16-368-0383
9.5
17.27
100
16
3/8"
/16"
11
16-368-0120
16-368-0126
16-368-0125
16-368-0123
/2" 12.7
20.83
100
20
/16"
1
13
SHIELDS FIRE-ACOL FUEL vENT
Shields Fire-Acol Fuel Vent hose resists gaso-
line/alcohol blended fuel and is fire resistant.
It features a weather/UV resistant NBR/PVC
cover. This hose is primarily used for fuel vent
lines (gasoline up to 85% ethanol blended fuels/
diesel fuels). It meets USCG Type A2 require-
ments for pleasure boats and meets SAE J1527
Type A2, ISO 7840 Type A2 and NMMA/CE Type
accepted standards. The temperature ranges
from -20�F to 160�F.
Bulk Pack
Max
Wt.
250' reel
50' R/O Ctn.
25' R/O Ctn
10' Polypac
I.D.
mm
O.D.
mm
WP
C
Code #
Code #
Code #
Code #
16-369-0580
16-369-0586
16-369-0585
16-369-0583
15.9
24.38
50
25
/8"
/32"
5
31
83
