SEASTAR CATAMARAN CYLINDERS
PART
NUMBER
DESCRIPTION
Catamaran Outboard Front Mount C/W Rodend
Catamaran Inboard Cylinder
Catamaran Inboard Cylinder
SEASTAR INBOARD CYLINDERS
PART
NUMBER
DESCRIPTION
SeaStar Cylinder, BA 125 ATM, Inboard Type
SeaStar Cylinder, BA 135 ATM, Inboard Type
SeaStar Cylinder, BA 150 ATM, Inboard Type
SeaStar Cylinder, BA 150-7TM, Inboard Type
SeaStar Cylinder, BA 175-7TM, Inboard Type
SeaStar Cylinder, BA150-9TM, Inboard Type
These cylinders are for single and dual rudder
vessels with two axis articulation and easy autopilot
interface. Cylinders are also supplied with bleeder
fittings.
OUTBOARD CYLINDER
The SeaStar Front Mount Pivot Cylinder is for
Catamaran designs. This cylinder will fit ALL engines
that require HC5375-3 steering cylinder. The
internal o-ring is designed to limit the amount of
fluid bypass decreasing the amount of re-alignment.
This cylinder is best used in applications that require
a liquid tie bar.
NOT recommended for single engine applications.
INBOARD CYLINDER & PICTURE OF HC5375-3 ABOVE
HYNAUTIC UNIVERSAL MOUNT
INBOARD CYLINDERS
PART
NUMBER
DESCRIPTION
Cylinder Assembly. 125-7", replaces HC5322-3
Cylinder Assembly. 125-9", replaces HC5323-3
double rod ended, each end held in place with internal
wire ties. Every cylinder is equipped with a swivel joint
at each end. One provides for a fixed mount attachment
point at the end of the housing to protect the moving
rod. The other swivel joint, located at the rod end, allows
for free movement of the cylinder without binding when
attached to the rudder arm.
STEERING - Cylinders
Features:
- All anodized aluminum construction
- Adjustable o-ring sealed ports
- Common components (i.e. end glands, pistons, seals)
New cylinders will be designated by HC53XX-3
