HYNAUTIC FIXED AND
PIVOT MOUNT INBOARD CYLINDERS
PART
NUMBER
DESCRIPTION
Cylinder Assy. 150-10" stroke fixed mount
Cylinder Assy. 200-10" stroke pivot mount
These Brass cylinders are for larger boats up to
approximately 70 ft. Tubes, ends, and external rods are
brass: cylinder rods are 17-4 stainless steel: mounts are
manganese bronze. There are two different types of
mounting packages for Brass cylinders: fixed mount and
pivot mount.
HYNAUTIC LARGE INBOARD CYLINDERS
CAPILANO INBOARD CYLINDERS
PART
NUMBER
DESCRIPTION
Cylinder Assy. 250-14.5" stroke balance c/w clevis
PART
NUMBER
DESCRIPTION
Cyl BA 150-7 TMB Bronze - Brass, Rod end ball joint type
Cyl BA 175-7 TMB Bronze - Brass, Rod end ball joint type
Cyl BA 200-7 TMB Bronze - Brass, Rod end ball joint type
Cylinder BA 175-7 TMC, Rod end clevis type
Cylinder BA 150-7 TMC, Rod end clevis type
Cylinder BA 200-7 TMC, Rod end clevis type
Cylinder BA200-11TMB (Rod end ball joint)
Cylinder BA200-11 TMC, 1" Shaft
The K-9 cylinder is a double rod end, tie rod constructed
hydraulic cylinder. This cylinder has a universal mount,
which allows two planes of pivot freedom. This cylinder
is equipped with a stainless steel ball joint. Porting is
through two 1/4" ports at each end of the cylinder.
A wide choice of cylinder configurations make it easy to
spec a system which can handle a variety of large boat
performance requirements and accommodate most
user preferences. Heavy duty brass cylinders. Two-axis
articulation. Easy installation for single or dual rudder
vessels.
STEERING - Cylinders
Features:
- All anodized aluminum construction
- Adjustable o-ring sealed ports
- Common components (i.e. end glands, pistons, seals)
New cylinders will be designated by HC53XX-3
