SeaStar Steering (Side Mount Cylinder) (Cont.)
| CSS Drop Down Menu by PureCSSMenu.com | < Previous Page|Next Page > |
57
®
ENGINE/CYLINDER
QTY.
CONFIGURATION
COMPONENT DESCRIPTION
REQ’D
MODEL
PART NO.
SINGLE ENGINE
CYLINDER
1
SIDE MOUNT
(SINGLE CYLINDER)
HELM
1
SEASTAR 1.7
Applications up to 300 HP maximum HOSE KIT
1
OUTBOARD HOSE
NUMBER OF TURNS: 4.8/5.7
OIL
3
SEASTAR OIL (QT.)
FOR EXTRA STEERING STATION ADD:
HELM
1
SEASTAR 1.7
FITTING KIT
1
ADD A STATION
HF6007-3
HOSE KIT
1
OUTBOARD HOSE
OIL
1
SEASTAR OIL (QT.)
DUAL ENGINE
CYLINDER
1
SIDE MOUNT
(SINGLE CYLINDER)
TIE BAR KIT
1
TIE BAR ONLY
Non-Counter-Rotating Applications
HELM
1
SEASTAR 1.7
to 300 HP max; Counter-Rotating
HOSE KIT
1
OUTBOARD HOSE
Applications to 600 HP maximum.
OIL
3
SEASTAR OIL (QT.)
NUMBER OF TURNS: 4.8/5.7
FOR EXTRA STEERING STATION ADD:
HELM
1
SEASTAR 1.7
FITTING KIT
1
ADD A STATION
HOSE KIT
1
OUTBOARD HOSE
OIL
1
SEASTAR OIL (QT.)
DUAL ENGINE
CYLINDER
2
SIDE MOUNT
(DUAL CYLINDERS)
TIE BAR KIT
1
TIE BAR ONLY
Non-Counter-Rotating Applications
HELM
1
SEASTAR 2.4
to 600 HP max; All Counter-Rotating HOSE KIT
1
OUTBOARD HOSE
Engine Applications
HOSE KIT
1
OUTBOARD HOSE
NUMBER OF TURNS: 7.5
HOSE KIT
1
OUTBOARD HOSE
FITTING KIT
1
TEE FITTINGS
OIL
3
SEASTAR OIL (QT.)
FOR EXTRA STEERING STATION ADD:
HELM
1
SEASTAR 2.4
FITTING KIT
1
ADD A STATION
HF6007-3
HOSE KIT
1
OUTBOARD HOSE
OIL
1
SEASTAR OIL (QT.)
OPTIONAL EQUIPMENT
BACK PLATE KIT
(FOR STANDARD HELMS)
20 DEGREE WEDGE
(FOR STANDARD HELMS))
AUTOPILOT FITTING KIT:
(FOR ALL HELMS)
TILT HELM - SEASTAR 1.7
REAR MOUNT HELM - SEASTAR 1.7
TILT HELM - SEASTAR 2.4
REAR MOUNT HELM - SEASTAR 2.4
POWER ASSIST STEERING
ORDERING GUIDE: SIDE MOUNT SYSTEMS
NOTES:
These recommendations apply to factory stock outboards only. Modified installations may require a higher capacity steering system. If in
doubt, contact SeaStar Solutions technical service for assistance. (Cylinder volume / helm displacement = number of turns.) For dual engines,
use SeaStar or engine manufacturer’s tie bar.
For all Seastar outboard systems: Use following option A or B:
A) Outboard hose: order standard lengths (cannot be cut to length.) Part No. HO51xx/HO57xx, where last two digits = length in feet.
B) Copper tube: 3/8" diameter copper tube and hose kit part No. HF5508.
WARNING:
Do NOT use SeaStar PRO helms with the unbalanced side mount cylinder. Doing so may cause steering wheel to lock up leading to
possible loss of steering causing property damage and/or personal injury.
STEERING - Outboard (Hydraulic)
